5052-H32 Aluminum coil

5052 represents the brand of the product, and the word "5" indicates that the modified product belongs to the aluminum-magnesium alloy product.
According to the chemical composition, it can be seen that the magnesium alloy content of the product is between 2.2-2.8%, and the density is 2.68.
Generally, enterprises take the median value of 2.5% magnesium alloy content in the processing process, so this series of aluminum plate can become AlMG2.5.

Category：

Aluminum Coil

+8619153118794

sales98@btcnsteel.com

E-mail

Message

Product Description

About the aluminum

5052 represents the brand of the product, and the word "5" indicates that the modified product belongs to the aluminum-magnesium alloy product. According to the chemical composition, it can be seen that the magnesium alloy content of the product is between 2.2-2.8%, and the density is 2.68. Generally, enterprises take the median value of 2.5% magnesium alloy content in the processing process, so this series of aluminum plate can become AlMG2.5.
H32 represents the processing state of the product H can be understood as incomplete annealing and work hardening state, that is, the product has been annealed, the hardness is degraded for processing molding, and in order to avoid the hardness of the product is too soft, and the appropriate work hardening. 32 means the modified product has been stabilized and the hardness is 1/4 hardness.
Grade of hardness: Usually H behind last Arabic numerals and hardness value is directly related to, such as H32 H34 H24 h18 last Arabic numerals represent the hardness, under the same brand of aluminum plate inside the Arabic numerals, the greater the hardness is higher, such as H34 hardness is higher than that of the most soft H32 state directly become zero state, more suitable as a stretch material. Arabic numerals take even numbers, 2, 4, 6, 8 the industry term becomes 1/4, 1/2, 3/4 full hard.
It can be concluded from the above that 5052H32 aluminum plate belongs to the aluminum magnesium alloy with magnesium alloy content near 2.5%. It has been stabilized by incomplete annealing and hardening processing, and its hardness is 1/4. Usually the product has strong corrosion resistance, good surface oxidation effect, good bending ability, 90 degree bending does not crack, is a typical sheet metal material, suitable for chassis cabinets and other bending products of classical materials.

Aluminum is a silver-white light metal, relatively soft, density 2.7g/cm3, melting point 660.4℃, boiling point 2467℃, aluminum and aluminum alloys have many excellent physical properties, has been very widely used. Aluminum has good reflection performance of light, reflecting ultraviolet light is stronger than silver, the purer aluminum is, its reflection ability is better, and the method of vacuum aluminum plating is commonly used to make high-quality mirrors. Vacuum aluminized film combined with polysilicon film becomes a cheap and lightweight solar cell material. Aluminum powder can maintain a silvery luster, often used to make paint, commonly known as silver powder. Pure aluminum conducts electricity very well, second only to silver and copper. In the electric power industry, it can replace part of copper for wires and cables. Aluminum is a good conductor of heat. It can be used to make various heat exchangers, heat dissipating materials and civil cookers in industry. Aluminum has good ductility, can be drawn into a fine wire, rolled into a variety of aluminum products, but also can be made into thinner than 0.01mm aluminum foil, widely used in packaging cigarettes, candy, etc.. Aluminum alloy has some better properties than pure aluminum, which greatly expands the application range of aluminum. For example, pure aluminum is soft, when a certain amount of copper, magnesium, manganese and other metals are added to aluminum, the strength can be greatly improved, almost equivalent to steel, and the density is small, not easy to rust, widely used in aircraft, cars, trains, ships, artificial satellites, rockets manufacturing. At -196 ° C, some steel is as brittle as glass, while some aluminum alloys increase in strength and toughness, making them cheap and lightweight cryogenic materials that can be used to store liquid oxygen and hydrogen for rocket fuel.

PRODUCT

Thickness	0.1-400mm，etc	Length:	100-12000mm，or as required
Width	20-3000mm，etc	Standard:	ASTM，AISI，JIS，GB， DIN，EN
Certification:	ISO, SGS，BV
Surface finish	mill,bright,polished,hair line,brush,sand Blast,checkered,embossed,etching,etc
Grade	1000 Series: 1050 1060 1070 1100 1200 1235 etc.
	3000 Series: 3003 3004 3005 3104 3105 3A21 etc.
	5000 Series: 5005 5052 5083 5086 5154 5182 5251 5754 etc.
	6000 Series: 6061 6063 6082 6A02 etc.
	7000 Series: 7050 7475 7075 etc.
Temper	H12,H14,H16,H18,H20,H22,H24,H26,H28,H32,H36,H38,HO,H111,H112,H114,H116,H118,H321.
Payment Terms	T/T, L/C at sight,West Union	Loading port	any port in China
Packing	standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Container size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
	40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
	40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)

Chemical composition

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others:	Others:	Al: Min.
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total	Al: Min.
1050	0.25	0.4	0.05	0.05	0.05	-	0.05	0.03	0.03	-	99.5
1060	0.25	0.35	0.05	0.03	0.03	-	0.05	0.03	0.03	-	99.6
1070	0.2	0.25	0.04	0.03	0.03	-	0.04	0.03	0.05	-	99.7
1100	0.95 Si + Fe		0.05~0.20	0.05	-	-	0.1	-	0.05	0.15	99
2014	0.5~1.2	0.7	3.9~5.0	0.4~1.2	0.2~0.8	0.1	0.25	0.15	0.05	0.15	-
2017	0.2~0.8	0.7	3.5~4.5	0.4~1.0	0.4~0.8	0.1	0.25	0.15	0.05	0.15	91.5 - 95.5
2024	0.5	0.5	3.8~4.9	0.3~0.9	1.2~1.8	0.1	0.25	0.15	0.05	0.15	-
3003	0.6	0.7	0.05~0.20	1.0~1.5	-	-	0.1	-	0.05	0.15	-
3A21	0.6	0.7	0.2	1.0-1.6	0.05	-	0.15	0.1-0.2	-	-	-
3004	0.3	0.7	0.25	1.0~1.5	0.8~1.3	-	0.25	-	0.05	0.15	-
3005	0.6	0.7	0.3	1.0~1.5	0.2~0.6	0.1	0.25	0.1	0.05	0.15	-
3105	0.6	0.7	0.3	0.3~0.8	0.2~0.8	0.2	0.4	0.1	0.05	0.15	-
5005	0.3	0.7	0.2	0.2	0.5~1.1	0.1	0.25	-	0.05	0.15	-
5052	0.25	0.4	0.1	0.1	2.2~2.8	0.15~0.35	0.1	-	0.05	0.15	-
5754	0.4	0.4	0.1	0.5	2.6~3.6	0.3	0.2	0.15	0.05	0.15	-
5A05	0.5	0.5	0.1	0.3-0.6	4.8-5.5	-	0.2	-	0.05	0.05	-
5083	0.4	0.4	0.1	0.4~1.0	4.0~4.9	0.05~0.25	0.25	0.15	0.05	0.15	-
6061	0.40~0.8	0.7	0.15~0.4	0.15	0.8~1.2	0.04~0.35	0.25	0.15	0.05	0.15	-
6082	0.70~1.3	0.5	0.1	0.4~1.0	0.6~1.2	0.25	0.2	0.1	0.05	0.15	-
7075	0.4	0.5	1.2~2.0	0.3	2.1~2.9	0.18~0.28	5.1~6.1	0.2	0.05	0.15	-

Mechanical behavior

Tensile strength (MPa)	Yield Strength (MPa)	Elongation （%）	Hardness（HV）
572	503	11	175

Physical properties

Density	Melting point	Elastic Modulus	Thermal conductivity
2.81 Kg/m³	477-635 ℃	71.7GPa	130 W/m.K

Annealing state

Trademark	Annealing state
1xxx: 1050, 1050A, 1060, 1100	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
3xxx: 3003, 3004, 3005, 3105	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
5xxx: 5005, 5052, 5754, 5083, 5086, 5182, 5049, 5251, 5454	O, H22, H24, H26, H28, H32, H34, H36, H38, H111
6xxx: 6061, 6082	T4, T6, T451, T651
2xxx: 2024	T3, T351, T4
7xxx: 7075	T6, T651
